PRODUCT BROCHURE
Lockformer Ovalizer 2.0 Oval Duct Forming Machine
Oval Duct Stretching
The all new Ovalizer 2.0 from Lockformer is the latest advancement in spiral pipe-forming technology. The Ovalizer 2.0 features a 10’ boom which can produce pipe up to 20’ lengths, as well as tooling with a Minor axis ranging from 6” to 36” to produce pipe with a Major axis ranging from 18” up to an impressive 96”. The Ovalizer 2.0 uses the latest technology in combination with a wedge style boom to make stretching oval duct easy, reliable and repeatable — resulting in a more efficient production process for your operation.
The Ovalizer 2.0 offers a full touch screen programmable logic controller (PLC) giving the operator the ability to save and recall parameters for fast, easy, and automatic set-up for production of duplicate parts. The PLC also features a re-stretch function that allows the operator to measure a finished part and simply input a dimension on the screen to automatically re-stretch the part if required.
Schedule a 1-on-1 Consultation with a Lockformer Technical Advisor
For over 75 years, Lockformer has been the most recognized name in the sheet metal machinery industry — leading the world in the production of HVAC duct and fittings fabrication equipment solutions including insulation cutting equipment, metal cutting systems, rectangular, round, and oval ductwork roll forming equipment, and HVAC CAD to CAM software Looking to improve the productivity and profitability of your HVAC duct and fittings fabrication operation? Looking for a solution to address a particular application? Schedule a no obligation, 1-on-1 consultation with a Lockformer Technical Advisor today.
