Lockformer Dual Head Gore-Locker

The Lockformer Dual Head Gore-Locker was designed for the production of HVAC round duct elbows, reducers, end-caps, and off-sets. Operator friendly, this machine also provides the power to fabricate quality standing seam fittings in-house in a single-machine platform with minimal power and floor space. On a single machine platform, the Lockformer Dual Head Gore-Locker offers the ability to flange/swage on one end, while simultaneously closing the seam at the other end. It also allows operators to modify controls when flanging/swaging, providing complete control of production speeds. After closing on the second station and creating a standing seam, the Lockformer Dual Head Gore-Locker delivers an airtight seal, eliminating the need for sealing or painting. Using minimal power and floor space, it also handles a variety of materials and thicknesses – up to 16 gauge (1.5mm) – to produce standing rib diameters from 4″ to 60″ (100 1500mm) with included tooling and can produce standing rib diameters from 4″ and 50″- 60″ with additional tooling. Added features of pneumatic-activated support rollers and a stronger closing station make the Lockformer Dual Head Gore-Locker safer and easier for the operator to remove parts.

Features

From Lockformer, the industry leader in HVAC sheet metal roll forming systems…

The Dual Head Gore-Locker is the cost-effective solution that allows you to produce spiral duct fittings such as gored elbows, reducers, end caps, and off-sets in-house. On a single machine platform using minimal power and floor space, the Dual Head Gore-Locker offers the ability to flange or swage on one end while simultaneously closing the seam at the other end delivering an airtight seal and eliminating the need for manual processes.

The Gore-Locker allows operators to modify controls when flanging and swaging, providing complete control of production speeds and the pneumatic-activated support rollers and a stronger closing station makes it safer and easier for the operator to remove parts.

The Dual Head Gore-Locker handles a variety of materials and thicknesses – up to 18 gauge (1.5mm) – to produce standing rib diameters from 4″ to 60″(100 1500mm) with included tooling.

Specifications

Model

Capacity

Diameter Range

Motor / Voltage

Dimensions / Weight

Lockformer Dual Head Gore-Locker

16 gauge

Included Tooling: 4" - 60"

Additional Tooling required for 4" and 52" -  60"



460V/3 Ph/60 Hz

Length: 106"
Width: 32"
Height: 44"
Weight: 2,310 lbs.
