Lockformer Vulcan 1600 Waterjet Cutting System

Name: Lockformer Vulcan 1600 Waterjet Cutting System
Brand: Lockformer
SKU: VU1600PLUS510
Availability: InStock

Cutting insulation manually is a slow, costly and inexact procedure. The Lockformer Vulcan 1600 Waterjet Cutting System automates the insulation cutting and fabrication process for mechanical contractors delivering an unrivaled level of quality and efficiency. The machine will cut up to 4″ fiberglass or 2″ foam insulation at a maximum positioning speed of 3,000 IPM. Whether you require precise insulation shapes for square to rounds, radius elbows or transitions, the Lockformer Vulcan 1600 Waterjet Cutting System can deliver savings of over 95%. With its precision speed and efficiency, the Lockformer Vulcan 1600 Waterjet Cutting System can fabricate insulation fittings for about one-tenth of what it costs to buy them or one-tenth the time it takes to cut them by hand while also reducing your scrap waste by up to 75%.

Part of the family of Lockformer Vulcan Cutting Systems which also includes:

Get a Quote

Request a 1-on-1 Consultation



Downloads

Features

Cutting insulation manually is a slow, costly and inexact procedure. The Lockformer Vulcan 1600 Fiberglass and Insulation Foam Waterjet Cutting System automates the insulation cutting and fabrication process for mechanical contractors delivering an unrivaled level of quality and efficiency. The machine will cut up to 4″ fiberglass or 2″ foam insulation at a maximum positioning speed of 3,000 IPM. Whether you require precise insulation shapes for square to rounds, radius elbows or transitions, the Lockformer Vulcan 1600 Waterjet Cutting System can deliver savings of over 95%. With its precision speed and efficiency, the Lockformer Vulcan 1600 Waterjet Cutting System can fabricate insulation fittings for about one-tenth of what it costs to buy them or one-tenth the time it takes to cut them by hand while also reducing your scrap waste by up to 75%.

System features:

60″ x 120″ effective cutting area
60″ x 240″ optional cutting table size
Up to 3,000 IPM cutting speed depending on the material type and thickness
4″ maximum cutting thickness
+/- 1/32″ positional accuracy
All Premium “plug-in” components
Unitized, fixture-welded, 3″ x 3″ steel tubing framework for strength and stability
Stand-alone control console
All axis home positioning using motor torque measurement
8″ x 8″ steel table leg pads with leveling feature

Drive features:

Dual precision Y-drive
Double deck, 24 strand steel, precision reinforced radial timing belts
HIWIN® linear x-axis bearing and way
3″ diameter x 128″ long, turned, ground and polished, heavy duty Y-axis guidance rail. Armaloy surface coated.
Precision cam followers
X-axis brush guard
Steel enclosed housing for X-axis servo drive motor
Y-axis drive housing enclosed and integral to the machine’s frame
SNC® brand vertical dual cylinder pneumatic torch lifter with adjustable up/down pressure

Table features:

1/4″ steel plate table perimeter
“Gull Wing” table design to protect the machine’s drive system and reduce the footprint size
Complete stainless steel table lining for rust-free performance longevity
Rectangular exhaust plenum at the back end of the table for easy access connection
Strategically located emergency stops [1 = controller; 1 = x-axis carriage]

Performance features:

CPUs have the highest performance in the PLC industry
Fastest hardware – PLCs , inverter, trigger inputs, etc.
Complex functions are programmable in high level languages
Scalable for quick development
Saleable and compatible hardware
Software can easily be adapted to different hardware configurations and machine applications

Machine Control features:

Lockformer 759 CNC-TS control system with 15″ color graphic industrial touch screen
Digital drive devices
Manual speed increase/decrease override
Kerf compensation
Auto home sense to set 0/0 automatically
Automatic corner slow down
Brushless AC servo motors with resolver feedback
Remote safety stop switches and current limiting drives for safety

Additional features:

Superior Control: one software tool for all applications and all systems. PLC, drives, communications, operator interface, programming, and diagnostics. Robust hardware made for the industry — no moving parts, no fans, no hard disks, plus a high ambient temperature specification.
Long-Term Availability: components made by the manufacturer, not outsourced. This enables control of components and allows Lockformer to provide components for the long haul
Better Maintenance: central program storage to all components in the system. Field replacements without programming for servo drives, HMIs, and other components.
Excellent Drive Diagnostic Features: ACOPOS software oscilloscope

Specifications

Software / Computer System: Windows 10® Professional PC with 19″ Monitor and Printer

Machine Control: 7590 CNC-TS and 15″ Color Graphic Industrial Touch Screen

Cutting Unit: KMT STREAMLINE SL-VI 15-HP and Waterjet Intensifier

Cutting Capacity: Up to 4″ fiberglass or 2″ foam insulation

Speed: Positioning speed and max cutting speed are the same at 3,000 in/min

Cutting Area and Table Capacity:

Standard: 5 ft x 10 ft
Optional: 5 ft x 20 ft
Table Capacity: 2,500 lbs

Dimensions / Weight:

Length: 168″
Width: 96″
Height: 63″ ( 5 ft x 10 ft table)
Weight: 4,500 lbs
